INSTALLATION
54
Meter wiring diagram
a - Meter lamp switch (optional)
b - Trim gauge
c - Tachometer
d - Analog gauge harness
e - Key switch harness
f - Trim sender
NOTE:
The parts of * mark is to be wired when a meter lamp switch
(optional) is connected.
38319
a
b
c
d
e
f
