INSTALLATION
53
4. Cut holes with 85 mm (3.346 in.) diameter for the tachometer
and 52.5 mm (2.067 in.) for the trim gauge.
a - Tachometer
b - Trim gauge
5. Connection of leads:
• Tachometer: EO, EPTO
• Trim gauge: EPTO
• Trim sender: EPTO
a
b
