Front Controls
a - Touch screen
b - Mark–Menu button
c - Standby–Auto button
d - Exit button
e - Rotary knob (press for enter function)
f - Goto–Pages button
g - In/out zoom, man overboard (MOB) button
h - Power/brightness
i - Card reader door
Troll Control Speed Range Specification
Troll Control Speed Range Specification
DTS Engine Model RPM
8.2 Mag with Emissions Control 650–1200
8.2 Mag H.O. with Emissions Control 650–1200
Digital Gauges
A Mercury SmartCraft System instrument package can be purchased for this product. A few of the functions the instrument
package will display are engine RPM, coolant temperature, oil pressure (requires a SmartCraft oil pressure sender kit), battery
voltage, fuel consumption, and engine operating hours.
