Section 4 - Maintenance
Page 50 90-8M0113924 eng DECEMBER 2015
Oil Removal with Drain Pump
1. Loosen the oil filter to vent the system.
2. Remove the dipstick.
3. Install the oil drain pump onto the dipstick tube.
a - Oil drain hose
b - Oil drain pump
4. Insert the hose end of the crankcase oil pump onto an appropriate container and use the handle to pump until the
crankcase is empty.
5. Remove the pump.
6. Install the dipstick.
Changing the Oil Filter
NOTE: Keep oil off the exhaust manifold and also the serpentine belt.
1. Remove and discard the oil filter. If any oil escapes from the oil filter, it will exit the oil drain slot. Place a container below
the oil drain slot to catch any oil.
a - Oil fill cap
b - Oil filter
c - Oil drain slot
2. Coat the sealing ring on the new filter with engine oil.
3. Install and tighten the oil filter securely following the filter manufacturer's instructions. Do not overtighten.
4. Remove the oil fill cap.
5. Use the dipstick to determine the amount of engine oil required. Replace the dipstick.
6. Add the required amount of the recommended oil to bring the level up to the bottom of the OK range on the dipstick.
7. With the boat at rest in the water, repeat steps 5 and 6 if necessary.
NOTE: Adding 0.95 L (1 US qt) of engine oil raises the level from the bottom of the operating range to the top of the
operating range.
All Models
Capacity Fluid Type
Engine oil (with filter) 6.5 L (7 US qt) Mercury 25W‑40 Synthetic Blend 4‑Stroke Engine Oil
8. Start the engine and operate for three minutes, checking for leaks.
