Section 5 - Storage
90-8M0113924 eng DECEMBER 2015 Page 87
Drain System Identification
Air-Actuated Single-Point Drain System
a - Manual pressure release valve
b - Threaded cap for air connection
c - Green indicators
a - Starboard side air‑actuated drain location
b - Port side air‑actuated drain location
Manual Drain System
a - Starboard side blue drain plugs
b - Port side blue drain plug
a
b
c
50399
a
b
50407
b
50408
