INTRODUCTION
3
Power amplifi ers
The speakers are driven by multiple independent high-power, low-
feedback power amplifi ers. The combination of idealised magnetic design,
careful star earthing, and very fast output devices gives the amplifi ers
extremely low noise, high detail, and fast bass.
The whole electronic assembly is supplied from substantial toroidal
transformers feeding high-quality, audiophile-grade capacitors.
Cabinet
Each DSP loudspeaker is carefully designed with internal bracing and
damping to give incredibly low levels of cabinet resonance, resulting in low
coloration and excellent mid-range transparency.
The DSP5200 and DSP5200HC are constructed using veneered ply, braced
and resin damped to produce an ultra-rigid cabinet.
The DSP5500, DSP5500C, and DSP5500HC are constructed using thick
veneered MDF sides bolted through a 1.5mm steel plate onto the main
cabinet, giving extremely low levels of cabinet resonance and excellent
bass-mid isolation.
In the DSP6000 and DSP6000C the bass drivers are mounted symmetrically
in pairs on the sides of the cabinet, cancelling vibration and giving
exceptionally low levels of cabinet resonance. The mid-range and treble
drivers are housed in a separate interlaminated head, to minimise bass-mid
interference. It is supported on the bass enclosure by three machined feet.
The DSP7000 cabinet is fabricated from curved pressure-laminated panels,
using multiple layers of selected woods and metal to achieve high stiffness
and damping. Its narrow tapered shape gives optimum dispersion over a
wide listening area. Each cabinet stands on three adjustable machined feet
which can be fi tted with spikes or skids.
Mounting options
In addition to the main vertical speakers, designed for use as the left/right
speakers in a system, each model includes a single horizontal centre and/or
a single vertical centre, designed for use as the centre speaker in a
surround system.
The DSP5000C, DSP5200HC, and DSP5500HC are horizontal centre versions,
designed for use either above or below a television.
The DSP5500C and DSP6000C are vertical versions, designed for use as
centre speakers, and they use fully shielded drive units so they can be
placed next to a television without interference.
