I) Introduction
CL-Profiler is an instrument that must be used in combination with a PC,
laptop or mini-PC. The instrument records movements of a probe as a
function of time. CL-Profiler is usable for different profile applications but
is specially developed for commutators and slip rings profiling.
II) Computer Installation
1) Computer requirements
- Computer with Windows 2000, XP, VISTA or Windows 7.
- Minimum 100MB free disk space.
- Minimum 512MB RAM memory.
- One or two free USB ports. We strongly recommend not to use a USB
hub, since it will decrease the sensor performance (add noise).
2) Software installation
Only connect the device to the USB port AFTER software installation. The
reason is that the USB driver must be installed first.
Run the setup file which is provided on CD or downloaded it on
www.cl-profiler.com (see downloads). After installing, the computer must
be restarted.
The device is ready to be used.
For users with administrator limitations;
- the USB plug of CL-Profiler must now be connected to the USB
port of the PC to activate the USB driver.
- Let Windows search for a driver.
- CL-profiler is now ready to be used.
- The file “CL-profiler” on C drive should not be limited.
