The digital input “DIN“ is “low“ for voltages below 4.6V and “high“ above 11.4 V. The output “Current
Loop“ can be set to currents between 0 and 22mA. The analog outputs 1 and 2 can be set to supply a
voltage between 0V and 10V.
Note! All test signals are permanently on until leaving the “I/O Test“ menu. It is the re-
sponsibility of the expert to assure that the I/O test does not interfere with the subsequent
connected systems and processes in an unintended way.
