Metal Work EB 80 - 3.3.6.4 Minimum Value; 3.3.6.5 Maximum Value; 3.3.6.6 Parameters Configuration

56
Object: No.1 04 Temperature Inputs 02282S08
Parameter Function Default value Default
Par1 Unit of measurement (0) 0 °C
Par2 Noise suppression (0) 0 50 Hz
Par3 CH1: Type of sensor (0) 0 No sensor
Par4 CH1: Type of connection (0) 0 2 wires
Par5
CH1: - BIT0: Cold joint compensation (1)
1
Internal cold junction
- BIT1: Measurement resolution (0) 0.1
- from BIT3 to BIT7 acquisition filter (0) Sync 3
Par6
CH1: - from BIT0 to BIT3: Filtering the value measuredo (3)
3
4 samples
- BIT4: Maximum value monitor (0) Disabled
- BIT5: Minimum value monitor (0) Disabled
- BIT6: Short-circuit signalling (0) Disabled
- BIT7: Sensor disconnected signalling (0) Disabled
Par7 CH1: Minimum temperature (Byte MSB) 1
384
Par8 CH1: Minimum temperature (Byte LSB) 128
Par9 CH1: Maximum temperature (Byte MSB) 127
32767
Par10 CH1: Maximum temperature (Byte LSB) 255
Par11 CH2: Type of sensor (0) 0 No sensor
Par12 CH2: Type of connection (0) 0 2 wires
Par13
CH2: - BIT0: Cold joint compensation (1)
1
Internal cold junction
- BIT1: Measurement resolution (0) 0.1
- from BIT3 to BIT7 acquisition filter(0) Sync 3
Par14
CH2: - from BIT0 to BIT3: Filtering the value measuredo (3)
3
4 samples
- BIT4: Maximum value monitor (0) Disabled
- BIT5: Minimum value monitor (0) Disabled
- BIT6: Short-circuit signalling (0) Disabled
- BIT7: Sensor disconnected signalling (0) Disabled
Par15 CH2: Minimum temperature (Byte MSB) 1
384
Par16 CH2: Minimum temperature (Byte LSB) 128
Par17 CH2: Maximum temperature (Byte MSB) 127
32767
Par18 CH2: Maximum temperature (Byte LSB) 255
Par19 CH3: Type of sensor (0) 0 No sensor
Par20 CH3: Type of connection (0) 0 2 wires
Par21
CH3: - BIT0: Cold joint compensation (1)
1
Internal cold junction
- BIT1: Measurement resolution (0) 0.1
- from BIT3 to BIT7 acquisition filter (0) Sync 3
Par22 CH3: - from BIT0 to BIT3: Filtering the value measuredo (3)
3
4 samples
- BIT4: Maximum value monitor (0) Disabled
- BIT5: Minimum value monitor (0) Disabled
- BIT6: Short-circuit signalling (0) Disabled
- BIT7: Sensor disconnected signalling (0) Disabled
Par23 CH3: Minimum temperature (Byte MSB) 1
384
Par24 CH3: Minimum temperature (Byte LSB) 128
Par25 CH3: Maximum temperature (Byte MSB) 127
32767
Par26 CH3: Maximum temperature (Byte LSB) 255
Par27 CH4: Type of sensor (0) 0 No sensor
Par28 CH4: Type of connection (0) 0 2 wires
Par29 CH4: - BIT0: Cold joint compensation (1)
1
Internal cold junction
- BIT1: Measurement resolution (0) 0.1
- from BIT3 to BIT7 acquisition filter (0) Sync 3
Par30 CH4: - from BIT0 to BIT3: Filtering the value measuredo (3)
3
4 samples
- BIT4: Maximum value monitor (0) Disabled
- BIT5: Minimum value monitor (0) Disabled
- BIT6: Short-circuit signalling (0) Disabled
- BIT7: Sensor disconnected signalling (0) Disabled
Par31 CH4: Minimum temperature (Byte MSB) 1
384
Par32 CH4: Minimum temperature (Byte LSB) 128
Par33 CH4: Maximum temperature (Byte MSB) 127
32767
Par34 CH4: Maximum temperature (Byte LSB) 255
3.3.6.4 Minimum value
Reference value for monitor minimum value.
3.3.6.5 Maximum value
Reference value for monitor maximum value.
3.3.6.6 Parameters configuration
