57
Object: No.1 Actuator
Parameter Function Default value Default
Par1 Virtual module (for future use) 0 -
Par2 Id electropilot 1 0 No electropilot
Par3 Id electropilot 2 0 No electropilot
Par4 Id FC1 0 No limit switch
Par5 Id FC2 0 No limit switch
Par6 Forward activation delay (MSB) 0 0 ms
Par7 Forward activation delay (LSB) 0 0 ms
Par8 Tolerance of forward activation delay % (1...15) 0 0 %
Par9 Backward activation delay (MSB) 0 0
Par10 Backward activation delay (LSB) 0 0
Par11 Tolerance of backward activation delay (1...15) 0 0 %
Par12 Actuator movement time (Byte4) 0 0 ms
Par13 Actuator movement time (Byte3) 0 0 ms
Par14 Actuator movement time (Byte2) 0 0 ms
Par15 Actuator movement time (Byte1) 0 0 ms
Par16 Tolerance of actuator movement time (1...15) 0 0 %
Par17 Actuator return time (Byte4) 0 0 ms
Par18 Actuator return time (Byte3) 0 0 ms
Par19 Actuator return time (Byte2) 0 0 ms
Par20 Actuator return time (Byte1) 0 0 ms
Par21 Tolerance of actuator return time (1...15) 0 0 %
3.3.6.7 I4.0 functions
N.B.: For a complete description of the functions, see the "EB 80 USER MANUAL of Industry 4.0 EtherNet/IP functions".
