6. TECHNICAL DATA
6.1 EtherNet/IP ELECTRICAL CONNECTION
GB
TECHNICAL DATA
Fieldbus 10 - 100 Mbit/S - Full-duplex - Half-duplex - Supports auto-negotiation and Quick Connect
Factory settings IP address: 192.168.193.32
Addressing Software - DHCP hardware
Supply voltage range V 12 -10% 24 +30%
Minimum operating voltage V
10.8
*
Maximum operating voltage V 31.2
Maximum admissible voltage V
32
***
Protection Module protected from overload and polarity inversion. Outputs protected from overloads and short-circuits.
Connections Fieldbus: 2 M12 F, D encoding, internal switch. Power supply: M8, 4-pin
Diagnostics EtherNet/IP: via local LED lights and software messages. Outputs: via local LED lights and state bytes
Bus power supply current absorption nominal Icc 180 mA at 24 V
Maximum number of pilots 128
Maximum number of digital inputs 128
Maximum number of digital outputs 128
Maximum number of analogue inputs 16
Maximum number of analogue outputs 16
Maximum number of inputs for temperatures 16
Data bit value 0 = non-active; 1= active
State of outputs in the absence of communication Configurable for each output: non-active, holding of the state, setting of a preset state
* Minimum voltage 10.8V required at solenoid pilots. Check the minimum voltage at the power supply output using the calculations shown on page 37.
*** IMPORTANT! Voltage greater than 32VDC will damage the system irreparably.
6.3 SIGNAL MODULES - S - DIGITAL OUTPUTS
TECHNICAL DATA 8 M8 Digital Outputs 16 Digital Input terminal board
Output voltage Corresponding to power voltage
Current for each connector mA max 500
Current for each module mA max 3000
Type of output Software-configurable PNP/NPN
Protection Overload and short-circuit protected inputs Overload and short-circuit protected outputs
Connections 8 M8 3-pole female connectors 4 connectors 12 pins with spring clamping
Input active signals One LED for each output
NB: Digital terminal block outputs are available from software version 2.16 and file EDS METALWORK EB80 - EIS V2.00
6.2 SIGNAL MODULES - S - DIGITAL INPUTS
TECHNICAL DATA 8 M8 Digital Inputs 16 Digital Inputs terminal board
Sensor supply voltage Corresponding to power voltage
Current for each connector mA max 200
Current for each module mA max 500
Input impedance kΩ 3.9
Type of input Software-configurable PNP/NPN
Protection Overload and short-circuit protected inputs
Connections 8 M8 3-pole female connectors 4 connectors 12 pins with spring clamping
Input active signals One LED for each input One LED for each output
NB: Digital terminal block inputs are available from software version 2.16 and file EDS METALWORK EB80 - EIS V2.00
