18
OPERATION MANUAL
PROGRAM MODIFICATION:
Press the SET icon in PROGRAM LIST to access this screen.
WARNING: The apron will automatically bend up once the start button is pressed.
Operation: Press NAME to enter a name. To make BEND 01 bend to 90º Press ANGLE and enter 90.
OFFSET is for bending thicker material, Entering 5 in OFFSET will make apron bend to 95º. Pressing delete
will skip the bend. Press EXIT to return to HOME page. Once on HOME page press PROGRAM CONFIRM to load
program then press the start button
to start bending. The apron will automatically bend up to the programed
angle, dwell for set value, return back down to 0 position, then the clamp will open automatically to the set open
height. Repeat process for next bend.zzzzzzz
USB Device: Press the Save to USB icon to access this screen
This screen is for saving or loading programs to or from a USB device.
Operation: To SAVE a program: Press and hold on the PROGRAM LIST screen for 3 seconds
to activate the “Save to USB” function. Press on the test1.csv to rename your program, press “ent” to save your
program then press OK. To LOAD a program: Press and hold on the PROGRAM LIST screen
for 3 seconds to activate the “Read from USB” function. Press on the eg: HAFCO.prd le and press OK.
Instructions Manual for PB-460 (S581B)
