METER AQUALAB PAWKIT - PAWKIT Components

10
SYSTEM
ELECTRICAL AND TIMING CHARACTERISTICS
Operating Temperature
Minimum 4 °C
Typical NA
Maximum 50 °C
Operating Environment
0–90% relative humidity (noncondensing)
Power
2–3 V 16 mm coin cell batteries (life of approximately 3 years)
COMPLIANCE
Manufactured under ISO 9001:2015
EM ISO/IEC 17050:2010 (CE Mark)
3.2 PAWKIT COMPONENTS
Figure10 shows the features on the top and Figure11 shows hardware on the bottom of
the PAWKIT.
LCD
I
button
II
button
Sample
cup
Figure10 PAWKIT features
