METER AQUALAB PAWKIT - Page 27

23
PAWKIT
Low battery
icon
Figure18 Low battery icon
Follow steps 1 through 6 below to replace battery.
1. Remove the PAWKIT bottom by unscrewing the two screws.
Screw
locations
MADE IN THE USA
METER Group, Inc. USA
Pullman, WA
PAWKIT
PWK00009000
Figure19 Battery compartment screws
2. Separate the stainless steel top and elastomer (which contains the batteries) from the
white plastic bottom.
