25.6.2009 Rev. 3.0
Spare parts
23
22=CHEF 220
A=3/N/PE∼400/230V 50Hz, C=3/N/PE∼380/220V 50Hz, G=3/N/PE∼415/240V 50Hz, H=3/PE∼230V 50Hz, I=3/PE∼220V
60Hz, J=3/PE∼380 50Hz, K=3/PE∼400V 50Hz, L=3/PE∼415V 50Hz, M=3/PE∼440V 60Hz
ID Code Model Voltage Description
Module:Heating, Steam exhaust
240 3591471 22 A,C,G,H,I Heating element 2350W, E1, E2
240 3595927 22 J,K,L Heating element 2350W, E1, E2
240 3646096 22 M Heating element 2350W, E1, E2
250 3518471 22 Seal
260 3493322 22 Washer
270 3493347 22 Nut
280 3599569 22 Upper plate
290 3399551 22 Lower plate
300 3751636 22 Steam outlet pipe
310 3440666 22 Valve
320 3590534 22 Rod
330 3021792 22 Washer
340 3285379 22 Cotter pin
350 3751621 22 Bracket
360 3591111 22 Flexible axle
To Next Page
