METREL EasiTEST MI 2087 AL2 - Connector Panel

MI 2087 AL2 EasiTEST Instrument description
9
2.2 Connector panel
1
Use original test cables only!
Max. allowed voltage between test terminals
and ground is 300V!
Max. allowed voltage between test terminals
is 500V!
Fig. 2: Connector panel
Legend:
1........Main test connector
