MI 2087 AL2 EasiTEST Measurement instructions
30
Step 3
q Press the START key and release it. Measurement will be carried out and
result displayed afterwards.
q Check calculated prospective short-circuit current by pressing the DISPLAY
key.
The current is calculated as follows: Ipsc = Un⋅1.06 / RL-PE
Where:
Un = 115V (100V ≤ UL-PE < 160V)
Un = 230V (160V ≤ UL-PE ≤ 264V)
If RCD trips during contact voltage measurement blinking “rcd” message will be
displayed blinking way.
Notes:
q Nominal input voltage range is 100 V ÷ 264V. If input voltage is out of the
range, the voltage value equipped with “!” mark will be displayed after pressing
START key. Warning sound is also emitted.
q The instrument will exchange L and N terminals automatically if N/L2 and L/L1
test leads (Universal test cable) are connected reversed way or terminals on
tested wall plug are reversed.
q If test result is out of display range “>1999 Ω” message will be displayed!
q Specified accuracy of tested parameters is valid only if mains voltage is stabile
during the measurement!
q “bat” message displayed during or after finishing the measurement means
batteries are too weak to guarantee correct result. Replace the batteries.
3.8 Line resistance RL-N/RL-L and prospective short-circuit
current
For general information concerning the measurement, refer to enclosed handbook
Measurements on electric installations in theory and practice.
How to carry out the measurement
Step 1
q Connect test cable (Universal test cable) to EasiTest.
q Set function switch to LOOP L-N, PSC position, L–N(L) voltage measurement
will start to run; see the figure below (left side):
