MI 3109 EurotestPV Lite Instrument description
14
3.3 Back side
1
2
3
Figure 3.3: Back panel
Legend:
1
Battery / fuse compartment cover
2
Back panel information label
3
Fixing screws for battery / fuse compartment cover
Figure 3.4: Battery and fuse compartment
Legend:
1
Fuse F2, F3
FF 315 mA / 1000 V d.c.
(Breaking capacity: 50 kA)
2
Serial number label
3
Battery cells
Size AA, alkaline / rechargeable NiMH
