U (DC+/DC-) 1500 V
PE - not connected to DC+ or DC-
Type Riso=[Roc]:
U (DC+/DC-)
PE - not connected to DC+ or DC-
At the end of test, capacitive objects are discharged to 30 V.
IEC 62446 Autotest
(Insulation)
If external voltage is detected on the test terminals the
instrument will check if conditions are appropriate for
proceeding with the test. Appropriate notifications are
displayed.
Conditions for starting the test (regarding external voltage on
test terminals):
U (DC+/DC-)
PE - not connected to DC+ or DC-
Uoc/Isc
I/U curve
IEC 62446 Autotest
(Uoc/Isc)
Conditions for starting the test (regarding external voltage on
test terminals):
U (DC+/DC-)
PE - not connected to DC+ or DC-
Consider correct environmental conditions and PV module
data! Otherwise, nominal and STC data will be wrong / will
not be calculated!
Hint
In case that wrong PV module data were used and (STC, nominal) results are wrong,
the instrument enables to change the PV module after the test.
See chapter Changing PV modules and other parameters in already performed
measurements.
1.1.4 General notes
• LCD screenshots in this document are informative only. Screens on the instrument
may be slightly different.
• Metrel reserve the right to make technical modifications without notice as part of the
further development of the product.
1.1.5 Markings on the instrument
Read the Instruction manual with special care to safety operation«. The
symbol requires an action!
