MI 2140 MI 2140 Omega &BetaPAT General presentation
5
1. 1. General presentation
1.1. Safety in use
• If the test equipment is used in manner not specified in this user manual the
protection provided by the equipment may be impaired!
• Read this instruction manual carefully, or use of the instrument may be dangerous
for the operator, for the instrument or for the equipment under test!
• Use only earthed mains outlets to supply the instrument!
• Do not use any damaged instrument, mains outlet, measurement leads or
damaged mains connection cable!
• A competent authorized person must carry out service, adjustment, or calibration
procedure!
• Only a competent person, familiar with hazardous voltage operations, should use
OmegaPAT and BetaPAT testers!
• During the measurements the appliance under test or the test leads should NOT
be touched – possible hazardous voltage.
• In case of abnormal behavior disconnect the instrument and return it to
manufacturer / distributor for service.
• Always handle the instrument as if the test sockets and leads have hazardous
voltages present.
• In some countries the leakage and touch leakage current measurements shall be
executed for normal connection of tested equipment and also for the connection
with changed L and N. It is advised to prepare appropriate test set-up for the test
with the changed lines. Consider local regulations.
Meaning of , signs on front panel:
Input section ............................................Switch off the instrument and disconnect all
test cables and mains cord before replacing
the fuses or opening the instrument
Flash terminal (MI2140 only)................... Dangerous voltage may be present.
Always handle as if the test leads are
energized.
FLASH
T16A/250V
T16A/250V
F1
F2
230V
50/60 Hz
16A
115V~/ ~
