MI 2140 MI 2140 Omega &BetaPAT General presentation
6
Other terminals........................................ Disconnect all equipment from the
instrument during the test except for the
equipment under test.
IEC cord connector is for test purposes only;
do not connect it to mains supply!
Dangerous voltage is present on the test
sockets during the measurement.
Measurements should only be carried out on
de-energized appliances.
Test sockets are intended only for
connection of tested appliance!
Maximum output current of any of two test
sockets (230 V / 115 V) is 16 A.
1.2. Features
Portable appliance testers MI2140 and MI2141 are instruments intended for testing the
safety of portable electrical equipment.
General functions of MI2140 and MI2141:
- Visual test.
- Earth bond test.
- Insulation test.
- Substitute leakage test.
- Flash test (MI2140 only).
- Leakage test.
- Touch leakage test.
- Functional (power) test.
- IEC cord test.
Benefits of MI2140 and MI2141:
- Fast and reliable performance of all tests necessary for testing the safety
of portable appliances.
- Large graphic LCD display with resolution of 240 x 128 dots, with back-
light.
- Over 4000 memory locations in data flash memory.
- Two RS232C communication ports for communication with PC, bar code
reader or printer.
- Soft touch keyboard with cursor keys.
- Built in real time clock.
The instrument is supplied with all necessary accessories for carrying out the tests.
EARTH BONDIEC CORD
