Calibrateur multifonctions CX 1651
102 Manuel de l'utilisateur
pin label signal limitation
1 L common terminal of multimeter input
2 INP input terminal of multimeter for voltage/current ranges Umax.=25 Vpp, Imax.=25 mA
3 -U low output terminal for DC voltage range
4 +U high output terminal for DC voltage range Umax.=20 Vss
5 -I low output terminal for DC current range
6 +I high output terminal for DC current range Imax.=25 mA
7 NG1 sort function output, contact 1 of relay Umax.=50Vpp, Imax.=100 mA
8 NG2 sort function output, contact 2 of relay Umax.=50Vpp, Imax.=100 mA
9 PTLI resistance temperature sensor input terminal Li
Umax.= 10Vpp. R<2 kΩ
10 PTHI resistance temperature sensor input terminal Hi
Umax.= 10Vpp. R<2 kΩ
11 PTLU resistance temperature sensor input terminal Lu
input terminal L on ranges 20, 200, 2000 mV
Umax.= 10Vpp. R<2 kΩ
12 PTHU resistance temperature sensor input terminal Hu
input terminal H on ranges 20, 200, 2000 mV
Umax.= 10Vpp. R<2 kΩ
13 TEST1 identification terminal of actually used adapter
14 TEST2 identification terminal of actually used adapter
15 NC not used
16 NC not used
17 0 identification terminal of actually used adapter
18 0 identification terminal of actually used adapter
19 NC not used
20 SIMLI RC simulator output, current terminal Lie Umax.= 10Vpp, Imax.=40mA
21 SIMHI RC simulator output, current terminal Hi Umax.= 10Vpp, Imax.=40mA
22 SIMLU RC simulator output, voltage terminal Hi Umax.= 10Vpp, Imax.=40mA
23 SIMHU RC simulator output, voltage terminal Hu Umax.= 10Vpp, Imax.=40mA
24 NC not used
25 NC not used
Functional inputs and outputs present at the connector can be best utilized using supplied cable adapters.
LCD display shows all information provided by the calibrator, e.g. set parameters of the signal, error messages,
setup information. The display is divided to several information sections.
