Metrohm 930 Compact IC Flex Manual - Short Instructions

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
3 Overview of the instrument
930 Compact IC Flex ChS/PP/Deg (2.930.1360)
￭￭￭￭￭￭￭￭
11
7
Exhaust opening
Labeled Exhaust. For extracting the air from
the vacuum chamber.
8
Auxiliary connection socket
For connecting an 891 Professional Analog
Out (2.891.0010).
9
Service connection socket
For Metrohm service only.
10
Transport locking screws
For securing the high-pressure pump when
transporting the instrument.
11
Drainage tubing connections
For connecting two drainage tubings that
guide the escaped fluid to the leak sensor
and from there to the waste container.
12
Base tray
With leak sensor.
13
Type plate
14
Serial number
15
Leak sensor connection socket
Labeled Leak Sensor. For connecting the
leak sensor connection cable.
16
Detector connection socket
Labeled Detector. For connecting Metrohm
detectors.
17
MSB connection sockets
Labeled MSB 1 and MSB 2. For connecting
MSB devices.
18
USB connection sockets
Labeled USB 1 and USB 2. For connecting
USB devices.
19
PC connection socket
For connecting the instrument to the com-
puter with the USB cable (6.2151.020).
20
Vacuum connection
Plugged with a stopper.
21
Power socket
Power socket for connecting the power
cable and power switch for switching the
instrument on and off.
