4.11 Metrohm Suppressor Module (MSM)
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
22
￭￭￭￭￭￭￭￭
930 Compact IC Flex ChS/PP/Deg (2.930.1360)
Inserting large rotors
6.2835.010
4 mm
6.2842.000
6.2842.200
Inserting small rotors
You need the adapter (6.2842.020) in order to insert a small rotor into the
suppressor drive.
4.11.2 Connecting the Metrohm Suppressor Module (MSM)
The three entries and exits of the suppressor units, numbered 1, 2 and 3
on the connecting piece, each have two permanently installed PTFE capil-
laries.
