CHAPTER 7: MVP MOTOR VEE PLATE
36
CAUTION: Use MAPP to determine the weight distribution between the front and rear of the grid. Use the
point(s) carrying the lesser weight to attach the MVP motor Vee plate.
NOTE: The MVP motor Vee plate is compatible with any Meyer Sound grid with front and rear center pickup
points.
MVP MOTOR VEE PLATE KIT CONTENTS
MVP Motor Vee Plate Weight: 20 lbs (9.1 kg)
MVP MOTOR VEE PLATE LOAD RATINGS
The MVP motor Vee plate has the following maximum load rating:
• 7,129 lbs (3234 kg) at a 5:1 safety factor
CAUTION: Potential risk of personal injury and damage to equipment. Do not exceed load ratings.
Table 5: MVP Motor Vee Plate Kit, PN 40.215.184.01
Quantity Part Number Item
1 45.215.184.01 MVP motor Vee plate
