7
CHAPTER 2: MRK-750 RIGGING UPGRADE KIT
The optional MRK-750 rigging kit allows the 750-LFC to be flown and groundstacked with the MG-MINA/LINA/750-LFC
multipurpose grid. The kit also allows 750-LFCs to be flown and groundstacked with LINA with no transition hardware. The
rigging kit is available as a factory-installed option or as a field upgrade and uses rugged GuideALinks and intuitive quick-
release pins to securely link adjacent loudspeakers in flown and groundstacked array configurations.
MRK-750 RIGGING UPGRADE KIT CONTENTS
Table 2: MRK-750 Rigging Upgrade Kit (PN 40.271.009.01)
Quantity Part Number Item
1 45.271.050.01 MRK-750 rigging end frame
(right)
1 45.271.051.01 MRK-750 rigging end frame
(left)
16 101.744 1/4-20 x 1.5 in btn head
screw, black oxide
16 101.244 1/4-20 x 1.5 in btn head
screw, stainless steel
10 134.039 0.25 in x 0.53 in quick-
release pin (black button)
1 640.096 Loctite Medium Strength
Threadlocker
