MG-MINA/LINA/750-LFC GRID ASSEMBLY GUIDE
51
MYA-MINA/LINA Dimensions
MYA-MINA/LINA Weight: 12.9 lbs (5.85 kg)
Figure 43: MYA-MINA/LINA Dimensions
17.49 in
[444 mm]
6.25 in
[159 mm]
4.00 in
[102 mm]
2.00 in
[51 mm]
(x6) Ø0.28 in
[Ø7 mm]
Ø0.56 in
[Ø14 mm]
Ø0.28 in
[Ø7 mm]
20.03 in
[509 mm]
22.53 in
[572 mm]
