MG-MINA/LINA/750-LFC GRID ASSEMBLY GUIDE
55
TIP: The M6 screws can be used in the pinning holes for fixed installations that will not require tilt adjustments
for the loudspeakers. For installations that will require tilt adjustments, use the M6 knobs in the pinning holes,
as they are more easily loosened and tightened.
The MYA-MINA/LINA mounting yoke can be suspended with a standard 1/2-inch C-clamp or half Cheesborough clamp
(Figure 48) (not included). Make sure the clamp is rated to support the full weight of the yoke and flown loudspeakers.
Figure 48: Flown MYA-MINA/LINA using MPA-3 bracket with Half Cheeseborough Clamp
