CHAPTER 11: MUB-MINA/LINA U-BRACKET
60
NOTE: For multiple flown cabinets, the MUB-MINA/LINA slot is not recommended for variable adjustments
since the angle could change over time due to the weight of the cabinets.
Table 12: MUB-MINA/LINA Flown, Fixed Angles
Flown, Maximum Downtilt
Fixed (0°, –5°)
Flown, Maximum Uptilt
Fixed (–5°, –10°)
Table 13: MUB-MINA/LINA Flown, Adjustable Angles
Flown, Maximum Downtilt
Adjustable (0° to 20°)
Flown, Maximum Uptilt
Adjustable (–10° to +10°)
0°
-5°
-5°
-10°
0°
-10°
-20°
+10°
