CHAPTER 14: MCF-750 CASTER FRAME
74
NOTE: Two versions of the MCF-750 caster frame are available from the factory—configured for cabinets with
the MRK-750 rigging kit (PN: 40.271.070.02) or without (PN: 40.271.070.03).
750-LFC cabinets need not be equipped with the MRK-750 rigging kit for transport with the caster frame. The loudspeaker
skids ensure that cabinets stack cleanly on the caster frame. However, to avoid tipping, straps (not included) should be
used when transporting cabinets that have not been fitted with the MRK-750 rigging kit.
Figure 66: MCF-750 Caster Frame, (3) 750-LFCs (without Rigging), and Straps (Not Included)
