Meyer 9100 BOSS RT - Page 41

1-800-325-9103
9100RT - 41 - www.meyermfg.com
KEY PART NUMBER QTY DESCRIPTION
1 100-8126-22 2 Outer Sprocket Spacer 4-19/32” Long
2 100-8126-23 2 Inner Sprocket Spacer 1-5/16” Long
3 100-8126-21 1 Front Apron Chain Shield Assembly
3A 100-8126-21-2 1 Front Apron Chain Shield Upper
3B 100-8126-21-1 1 Front Apron Chain Shield Lower
4 25-8201 4 Apron Chain Tightener Bolt
5 110-667B7-2.00-2 4 Idler Sprocket W / Bushing
13-0026 4 Bushing 1-1/2” Long; (Prior to SN 1391228, Excluding 1391225)
13-0025 4 Bushing 2” Long; (SN 1391228 & Later, Including 1391225)
6 25-8034 4 Tightener Nut Weldment
7 851-3118-1Z 6 5/16” x 1” Bolt
8 23-0114 2 Idler Shaft
9 11-0303 2 Main Apron Assy. (24 Ft.) DH667XH
11-0304 2 Main Apron Assy. (26 Ft.) DH667XH
11-0305 2 Main Apron Assy. (28 Ft.) DH667XH
11-0306 2 Main Apron Assy. (30 Ft.) DH667XH
11-0309 2 Main Apron Assy. (36 Ft.) DH667XH
11-0311 2 Main Apron Assy. (40 Ft.) DH667XH
10 11-0107-2-D AR Pintle Chain Link - D667XH W / 2 D-Pins & Cotters
11 11-0107-6 AR Rivet, 7/16” x 1-1/8”
12 11-0171-1 AR Slat 35-7/8” Long
13 11-0107-3-D AR Attachment Link D667XH W / 2 D-Pins & Cotters
14 815-5013-Z 8 1/2”-13 Nylon Lock Nut
15 851-5013-1Z 8 1/2”-13 x 1” Bolt
16 30-0002 4 1/8” NPT Straight Zerk
17 100-8126-8 1 9100 Main Drive Shaft Assembly (Prior to SN 1791271)
23-0169 1 9100 Main Drive Shaft Assembly (SN 1791271 & Later)
18 11-0171 AR Slat w/Attachment Links D667XH
19 100-8126-20 1 Front Gate Center Support
20 100-8125-1-14-2-SR 2 Right Drive Shaft Bearing Assembly
100-8125-1-14-2-1 2 Drive Shaft Bearing
21 100-8125-1-14-2-SL 2 Left Drive Shaft Bearing Assembly
100-8125-1-14-2-1 2 Drive Shaft Bearing
22 100-8125-1-27-1 1 Drive Shaft Spacer Washer
23 100-8126-8-1 1 Rear Main Drive Shaft (Prior to SN 1791271)
23-0169-1 1 Rear Main Drive Shaft (SN 1791271 & Later)
24 35-0034 4 5/8” x 7/16” x 2” 1045 Key (Prior to SN 1791271)
135-6363-2-1 4 5/8” x 7/16” x 2” 1045 Key (SN 1791271 & Later)
25 633-0024 4 Drive Shaft Spacer Washer
26 633-0025 4 Rear Drive Spacer
27 827-5013-.375 4 1/2”-13 x 3/8” Set Screw
28 827-5013-.5 4 1/2”-13 x 1/2” Set Screw
29 100-8126-21-3 1 Front Shield Latch
30 33-0051 1/2 55 mm External Retaining Ring (Prior to SN 1791271)
33-0062 1/2 2-3/8” External Retaining Ring (SN 1791271 & Later)
31 110-667B7-2.38-1 4 Rear Main Drive Sprocket
32 35-0041 2 10 mm x 16 mm x 5.094” 1045 Key (Prior to SN 1791271)
135-5050-5-2 2 1/2” x 1/2” x 5” 1045 Key (SN 1791271 & Later)
33 See Page 42 2 Rear Gearbox
