1-800-325-9103
9100RT - 53 - www.meyermfg.com
HYDRAULIC PRESSURE LINE GATE DELAY
SN 1591263 & LATER
KEY PART NUMBER QTY DESCRIPTION
1 155-5406-12-6 1 3/4” x 3/8” Bushing (Truck Mount / Ag Cart)
155-2406-16-8 1 1” x 1/2” Adapter (5th Wheel Trailer)
2 155-06R12-200-1 1 3/8” x 200” Hose (Truck Mount / Ag Cart)
155-06R16-178-1 1 3/8” x 178” Hose (5th Wheel Trailer)
32-0049 1 5/8” Loom Clamp
851-2520-.75Z 1 1/4” 20 x 3/4” Machine Bolt
815-2520-Z 1 1/4”-20 Nylon Locknut
3 55-0055 1 3/8” x 3/8” Elbow Fitting (Prior to SN 1891287)
155-6901-06-06 1 90 Degree Adapter Fitting (SN 1891287 & Later)
4 155-D-1.25-10-1 1 Hydraulic Cylinder
155-1.25-.75-1-K 1 Hydraulic Cylinder Seal Kit (Prior to SN 1891287)
155-D-1.25-SK 1 Hydraulic Cylinder Seal Kit (SN 1891287 & Later)
5 55-0307 1 3/8” NPT Breather Vent (Prior to SN 1891287)
6 24-8017 1 Hose Shield for High Gate (With Extension)
24-8018 1 Hose Shield for Standard Gate (No Extension)
7 25-8451 1 Lower Gate Delay Mounting Bracket
8 25-8453 1 Upper Gate Delay Mounting Bracket W/Shear Bolt
9 25-8097-1 AR Spacer Washer
808-1.31-2.00-.135 AR AR Spacer Washer
10 851-5013-1.5Z 1 1/2” - 13 x 1-1/2” Bolt
11 815-5013-Z 1 1/2” Nylon Locknut
12 155-CV-375-1 1 Check Valve 3/8 NPT x FEM NPT
13 155-6600-16-16-16 1 Swivel Tee Fitting (5th Wheel Trailer)
