11.0 SPECIFICATIONS
See the “Forage Box Truck Mount Specifications and Mounting Instructions” for additional information. These
instructions may also be found at www.meyermfg.com/specifications.php.
DIMENSIONS 9124RT 9126RT 9128RT 9130RT 9130T-RT 9136T-RT 9140T-RT
Inside Length 24’ 8” 26’ 28’8” 30’ 30’ 36’8” 40’
Inside Width 98” 98” 98” 98” 98” 98” 98”
Inside Height - no extension 72” 72” 72” 72” 72” 72” 72”
Inside Height w/14” extension 85.5” 85.5” 85.5” 85.5” 85.5” 85.5” 85.5”
Overall Length 25’9” 27’1” 29’9” 31’1” 31’1” 37’9” 41’1”
Overall Width 102” 102” 102” 102” 102” 102” 102”
Overall Height - no extension (top of gate) * 103.5” 103.5” 103.5” 103.5” 147” 147” 147”
Overall Height w/14” extension (top of gate) * 115.5” 115.5” 115.5” 115.5” 159” 159” 159”
Overall Side Height - no extension * 88.25” 88.25” 88.25” 88.25” 130.5” 130.5” 130.5”
Overall Side Height - extension * 102” 102” 102” 102” 144.5” 144.5” 144.5”
Stringer Width (Truck/Trailer Mount) 33.5” 33.5” 33.5” 33.5” N/A N/A N/A
Capacity (struck level) Cu. Ft. - no extension 1200 1260 1390 1460 1460 1780 1920
Capacity (struck level) Cu. Ft. - w/14” extension 1400 1495 1640 1720 1720 2105 2305
*Height measurements - Straight Truck Mounted Units require hardware which adds approximately 1.5” to height.
SPECIFICATIONS 9124RT 9126RT 9128RT 9130RT 9130T-RT 9136T-RT 9140T-RT
Maximum Net Load (off road rating) 27 ton 27 ton 27 ton 27 ton 30 ton 30 ton 30 ton
Apron Chains (pintle) 667XH 667XH 667XH 667XH 667XH 667XH 667XH
Rear Drive Shaft (HD Solid Shaft) 2-3/8” 2-3/8” 2-3/8” 2-3/8” 2-3/8” 2-3/8” 2-3/8”
Power Source / Direct Geardrive hyd /
dual
hyd /
dual
hyd /
dual
hyd /
dual
hyd / dual hyd / dual hyd / dual
Upright Spacing 16” o/c 16” o/c 16” o/c 16” o/c 16” o/c 16” o/c 16” o/c
Upright / Cross Member Construction 2x2
tubing
2x2
tubing
2x2
tubing
2x2
tubing
2x2
tubing
2x2
tubing
2x2
tubing
Enclosed Side Frame/Cross Member Union STD STD STD STD STD STD STD
Unloading Time (Dependent of Hyd. System) 50
seconds
50
seconds
50
seconds
55
seconds
55
seconds
65
seconds
65
seconds
