Meyer 9100 BOSS RT - 19 - 0204 Rear Gearbox; Rear Gearbox

Meyer Manufacturing Corporation - 42 - 9100RT
REAR GEARBOX
RT-001
6
5
2
13
3
5
6
13
14
11
8
9
7
17
16
15
18
19
1
10
11
14
4
12
22
11
14
20
10
21
USE ONLY EP 80W-90
GEAR LUBE ONLY
NOTE: The seal for the hydraulic motor (Key 21) should be installed dry or with light
oil. The hydraulic motor mounting bolts should be torqued to 63 ft-lbs (or 85 N-m).
