Meyer 9100 BOSS RT - Page 45

1-800-325-9103
9100RT - 45 - www.meyermfg.com
7 810-5013-Z 6 1/2-13 Spin Locknut
8 100-8080-15 1 9124 Center Floor Holddown Channel - Front 49”
100-8133-6 1 9126 Center Floor Holddown Channel - Front 65”
100-8132-6 1 9128 Center Floor Holddown Channel - Front 97”
100-8130-5 1 9130 Center Floor Holddown Channel - Front 113”
100-8127-5 1 9136 Center Floor Holddown Channel - Front 193”
100-8125-1-21 1 9140 Center Floor Holddown Channel - Front/Rear 233”
9 709-48-287 2 9124 Superslick Floor Panel 48” x 287”
709-49-302.5 2 9126 Superslick Floor Panel 49” x 302-1/2”
709-49-334.5 2 9128 Superslick Floor Panel 49” x 334-1/2”
709-49-350.5 2 9130 Superslick Floor Panel 49” x 350-1/2”
709-49-431.5 2 9136 Superslick Floor Panel 49” x 431-1/2”
709-49-471.5 2 9140 Superslick Floor Panel 49” x 471-1/2”
802T-3118-3SS 14/22 5/16”-18 x 3” Truss Head Stainless Steel Machine Screw
(Shorter Than 30’; 30’ & Longer) (Prior to SN 1691284)
802T-3118-1.25SS 14/22 5/16”-18 x 3” Truss Head Stainless Steel Machine Screw
(Shorter Than 30’; 30’ & Longer) (SN 1691284 & Later)
815-3118-Z 14/22 5/16”-18 Zink Nylon Insert Locknut (Shorter Than 30’; 30’ & Longer)
10 100-8127-9 4/2/2/4/2 Stainless Steel Side Panel 72” x 55-3/4” (9124 / 28 / 30 / 32 / 36)
100-8126-10 2/4/4/4/4/6/8 Stainless Steel Side Panel 72” x 98” (9124 / 26 / 28 / 30 / 32 / 36 / 40)
100-8130-6 2/2 Stainless Steel Side Panel 72” x 23-3/4” (9126 / 9130)
100-8126-11 1 Stainless Steel Side Panel - Right Rear 72” x 97” (All Models)
100-8126-12 1 Stainless Steel Side Panel - Left Rear 72” x 97” (All Models)
11 851-2520-.75Z AR 1/4”-20 x 3/4” Bolt
12 815-2520-Z AR 1/4”-20 Nylon Insert Locknut
13 25-8008 2 8’ Fender (Optional On Truck Mount Models)
14 49-0131 1 Front Gate Belting
15 100-8080-6 1 Right Hand Gear Box Cover Assembly
16 100-8080-5 1 Left Hand Gear Box Cover Assembly
17 100-8126-14 2 9100 Right / Left Side Chain Guide 120”
18 100-8080-38 2 Front Floor Cover
850-2520-1.25Z
6
1/4”-20 x 1-1/4” Carriage Bolt
805-0025-Z
6
1/4” Flat Washer Zinc
815-2520-Z
6
1/4”-20 Zinc Nylon Insert Locknut
19 24-8209-1 1 Rear Lower Frame Cover (Trailer Mount Only)
20 49-0092 2 30” Meyer Mud Flap
21 25-8212 2 Mud Flap Attaching Strap
22 851-3816-1.25Z 8 3/8”-16 x 1-1/4” Bolt
23 805-0038-Z 8 3/8” Washer
24 815-3816-Z 8 3/8”-16 Nylon Insert Locknut
25 33-0044 1 Manual Holder W/ Cap
26 100-8125-1-21 1 9100 Center Floor Holddown Channel - Rear 233”
27 100-8126-15 2/4 9100 Right / Left Side Chain Guide-Center/Center Rear 120”
28 100-8134-6 2 9124 Right / Left Side Chain Guide - Front 43.25”
100-8133-7 2 9126 Right / Left Side Chain Guide - Front 59.25”
100-8132-7 2 9128 Right / Left Side Chain Guide - Front 91.25”
100-8126-16 2 9130 Right / Left Side Chain Guide - Front 107.25”
100-8127-6 2 9136 Right / Left Side Chain Guide - Front 67.25”
100-8126-16 2 9140 Right / Left Side Chain Guide - Front 107.25”
29 100-8129-9 1 Front Left Floor Cap End Cap
30 100-8129-8 1 Front Right Floor End Cap
31 100-8080-27 AR L / R Floor Cap Support Piece
32 100-8080-1-10 1 LH Main Drive Shaft Cover (Welded To Frame)
33 100-8080-1-11 1 RH Main Drive Shaft Cover (Welded To Frame)
34 701-.75-1.75-16 2/2/4 9126 / 28 / 36 16’ Chain Return Extension
701-.75-1.75-20 4/4/4/6/4/8 9124 / 26 / 28 / 30 / 36 / 40 20’ Chain Return
35 49-0155 1 Center Belt Strip
