9100RT - 47 - www.meyermfg.com
KEY PART NUMBER QTY DESCRIPTION
1 655-0001 2 Dual Drive Hydraulic Motor (Prior to SN 1791225)
55-0088-KIT AR Dual Drive Eaton/Char-Lynn Motor Seal Kit (Prior to SN 1891371)
155-WS-12.3-3 2 Dual Drive Hydraulic Motor (SN 1791225 & Later)
155-WS-SK-1 AR Dual Drive White WS Series Motor Seal Kit (SN 1891371 & Later)
2 55-0048 4 5/8” x 3/4” Swivel Adapter
3 55-0007-B-GDRL 1 3/4” Check Valve (Truck Mounted)
55-0007-B 1 3/4” Check Valve (Ag Cart Mounted)
4 851-5013-1.25Z 2 Torque Plate Bolt For Retainer Washer 1/2” x 1-1/4”
5 55-0126 2 3/4” Hydraulic Pipe x 249” (9124 / 26 / 28 / 30 / 32)
6 55-0079 4 3/4” Black Steel Tee Fitting
7 851-3816-2Z AR 3/8”-16 x 2” Bolt
8 815-3816-Z AR 3/8”-16 Nylon Insert Locknut
9 925-3807-3 2 Retaining Washer
10 55-0129 2 3/4” 90 Degree Swivel Fitting
11 55-0240 2 3/4” Hydraulic Extension Pipes x 19.5” (9124)
55-0241 2 3/4” Hydraulic Extension Pipes x 35.5” (9126)
55-0242 2 Hydraulic Extension Pipes x 67.5” (9128)
55-0243 2 3/4” Hydraulic Extension Pipes x 83.5” (9130)
12 831-M12-1.75-40 8 Motor Allen Head Cap Screw 12mm x 40mm
13 100-8125-1-15 1 Gearbox Torque Plate, Left
14 100-8126-33 8 Pipe Holder Clamp
100-8126-3-1-7 2 Pipe Holder
25-0210-3 AR AR Hydraulic Pipe Clamp Spacer
15 15 55-0045 2 3/4” Hydraulic Hose x 26” Long
16 55-0030 4 3/4” Black Steel Coupler
17 851-M16-2.0-35-Z 6 Torque Plate Bolt 16mm x 35mm
18 See Page 42 2 RT 430 Gearbox (Specify LH or RH when ordering)
19 55-0029 4 3/4” Hydraulic Hose x 36” Long
20 55-0081 1 3/4” Plug
21 100-8125-1-16 1 Gearbox Torque Plate, Right
22 55-0079 1 3/4” Tee Fitting (Truck Mounts Only)
23 55-0109 1 Pressure Gauge (Truck Mounts Only)
55-0174 1 3/4” - 1/4” Adapter Fitting (Truck Mounts Only)
