Meyer 9100 BOSS RT - Page 49

1-800-325-9103
9100RT - 49 - www.meyermfg.com
6 155-2405-16-16 3 1-5/16”-12 JIC x 1” NPTF Female Adapter Fitting
7 55-0260 1 1” Hydraulic Extension Pipe x 21.5” (9130T) (Prior to Serial # 1391220)
55-0265 1 1” Hydraulic Extension Pipe x 51.5” (9130T) (Serial # 1391220 & Later)
55-0256 1 1” Hydraulic Extension Pipe x 101.5” (9136T) (Prior to Serial # 1391220)
55-0264 1 1” Hydraulic Extension Pipe x 131.5” (9136T) (Serial # 1391220 & Later)
55-0251 1 1” Hydraulic Extension Pipe x 141.5” (9140T) (Prior to Serial # 1391220)
55-0263 1 1” Hydraulic Extension Pipe x 171.5” (9140T) (Serial # 1391220 & Later)
8 55-0259 1 1” Hydraulic Extension Pipe x 24” (9130T) (Prior to Serial # 1391220)
55-0265 1 1” Hydraulic Extension Pipe x 51.5” (9130T) (Serial # 1391220 & Later)
55-0255 1 1” Hydraulic Extension Pipe x 104” (9130T) (Serial # 1391220 & Later)
55-0264 1 1” Hydraulic Extension Pipe x 131.5” (9136T) (Serial # 1391220 & Later)
55-0250 1 1” Hydraulic Extension Pipe x 144” (9140T) (Prior to Serial # 1391220)
55-0263 1 1” Hydraulic Extension Pipe x 171.5” (9140T) (Serial # 1391220 & Later)
9 955-4005-1 1 1” Check Valve
10 155-5000-16-16 1 1” Coupler
11 955-8018 1 1” Hydraulic Pipe x 252” (9130T / 36T / 40T) (Prior to Serial # 1391220)
55-0262 1 1” Hydraulic Pipe x 249” (9130T / 36T / 40T) (Serial # 1391220 & Later)
12 955-8018 1 1” Hydraulic Pipe x 252” (9130T / 36T / 40T) (Prior to Serial # 1391220)
55-0262 1 1” Hydraulic Pipe x 249” (9130T / 36T / 40T) (Serial # 1391220 & Later)
13 155-2606-16-16-16 1 1” Tee Fitting, Drilled & Tapped 3/8” NPT
14 155-304-C-16 1 1-5/16”-12 JIC Cap
15 155-16100R12-75-1 2 1” Hydraulic Hose x 75” Long
16 155-6500-16 1 1-5/16”-12 JIC 90 Degree Swivel Fitting
17 155-2603-16 2 1-5/16”-12 JIC Tee Fitting
18 155-12100R12-36-1 4 3/4” Hydraulic Hose x 36” Long
19 155-6400-16-10 4 1-5/16”-12 JIC To 7/8” Adapter Fitting
20 655-0001 2 Dual Drive Hydraulic Motor (Prior to SN 1791225)
55-0088-KIT AR Dual Drive Eaton/Char-Lynn Motor Seal Kit (Prior to SN 1891371)
155-WS-12.3-3 2 Dual Drive Hydraulic Motor (SN 1791225 & Later)
155-WS-SK-1 AR Dual Drive White WS Series Motor Seal Kit (SN 1891371 & Later)
21
See Page 42
2 RT 430 Gearbox (Specify LH or RH When Ordering)
22 831-M12-1.75-40 8 Motor Allen Head Cap Screw 12mm x 40mm
23 851-5013-1.25Z 2 Torque Plate Bolt For Retainer Washer 1/2” x 1-1/4”
24 925-3807-3 2 Retaining Washer
25 100-8125-1-15 1 Gearbox Torque Plate, Left
26 851-M16-2.0-35-Z 6 Torque Plate Bolt 16mm x 35mm
27 55-0234 1 1” 90 Degree Fitting (Prior to Serial # 1391220)
55-0235 1 Female Right Hand Sweep (Serial # 1391220 & Later)
28 55-0234 1 1” 90 Degree Fitting (Prior to Serial # 1391220)
55-0236 1 Female Left Hand Sweep (Serial # 1391220 & Later)
29 100-8125-1-16 1 Gearbox Torque Plate, Right
30 806-0125-Z 2 1-1/4” Internal Tooth Lock Washer
31 155-6500-16 1 1-5/16”-12 JIC 90° Swivel Fitting (Prior to SN 1591263)
155-6600-16-16-16 1 Swivel Tee (SN 1591263 & Later)
