9100RT - 73 - www.meyermfg.com
KEY PART NUMBER QTY DESCRIPTION
A Air Controlled - Prior to Serial # 1491246 (Truck Mount & 5Th Wheel Trailer)
B Air Controlled - Serial # 1491246 & Later (Truck Mount & 5Th Wheel Trailer)
Hydraulic Controlled - Serial # 1391201 & Later (AG Trailer Models Only)
1 100-8175-9 1 Left Top Mount Extension Weldment, Standard
100-8175-5 1 Left Top Mount Extension Weldment, High
2 100-8175-3 1 Top Cross Support Tube Assembly
3 100-8175-10 1 Right Top Mount Extension Weldment, Standard
100-8175-4 1 Right Top Mount Extension Weldment, High
4 100-7041-11 2 Inner Cylinder Pin
5 100-7078 4 Hydraulic Cylinder Pivot
6 100-7041-10 2 Outer Cylinder Pin, Hydraulic
7 100-8178 1 Right Door Assembly Complete, Standard
100-8176 1 Right Door Assembly Complete, High
8 100-8175-8 2 Pivot Rod Weldment
9 100-8175-7 1 Right Hinge Weldment
10 30-0002 6 1/8” Straight Grease Fitting
11 100-8177-2 1 Left Hand Door Panel
100-8175-2 1 Left Hand High Door Panel
12 100-8178-2 1 Right Hand Door Panel
100-8176-2 1 Right Hand High Door Panel
13 100-8178-1 1 Right Door Weldment, Standard
100-8176-1 1 Right Door Weldment, High
14 49-0136 1 Bottom Door Belt - Left Outer
15 49-0135 1 Bottom Door Belt-Right Inner
16 100-8100-6-L-ASSY 2 Door Latch Assembly W / Roll Pin, Spring, Hardware
29-0022 2 Double Door Torsion Spring
17 100-8175-16 1 Right Shield Weldment
18 100-8175-17 1 Left Shield Weldment
19 100-8177 1 Left Door Assembly Complete, Standard
100-8175 1 Left High Door Assembly Complete, High
20 100-8177-1 1 Left Door Weldment, Standard
100-8175-1 1 Left High Door Weldment, High
21 49-0133 1 Bottom Door Belt-Left Inner
22 100-8175-6 1 Left Hinge Weldment
23 100-7081 2 Air Cylinder Pivot (Prior to Serial # 1491246)
24 100-7080 4 Air Cylinder Centering Bushing, Lower (Prior to Serial # 1491246)
25 16-0027 2 1/2”-20 Swivel Eyelet (Prior to Serial # 1491246)
26 826-5020-Z 2 1/2”-20 Jam Nut (Prior to Serial # 1491246)
27 805-0050-Z 4 1/2” Flat Washer (Prior to Serial # 1491246)
28 851-5013-4.5Z 2 1/2”-13 x 4-1/2” Bolt (Prior to Serial # 1491246)
29 815-5013-Z 2 1/2” Nylon Locknut (Prior to Serial # 1491246)
30 49-0134 1 Bottom Door Belt Right Outer
31 24-8015 1 Double Door Hose Shield
24-8014 1 High Double Door Hose Shield
32 49-0150 2 Door Belting
33 100-7042-3 4 Double Door Gate Stop
