KEY PART NUMBER QTY DESCRIPTION
1 25-8516 1 Left Rear Screen Side Extension
25-8520 1 Left Rear Solid Side Extension
2 25-8517 1 Right Rear Screen Side Extension
25-8521 1 Right Rear Solid Side Extension
3 25-8518 1 9124 Left Front Screen Side Extension
25-8522 1 9124 Left Front Solid Side Extension
25-8526 1 9126 Left Front Screen Side Extension
25-8524 1 9126 Left Front Solid Side Extension
25-8546 1 9128 Left Front Screen Side Extension
25-8544 1 9128 Left Front Solid Side Extension
25-8542 1 9130 Left Front Screen Side Extension
25-8540 1 9130 Left Front Solid Side Extension
25-8534 1 9136 Left Front Screen Side Extension
25-8532 1 9136 Left Front Solid Side Extension
25-8530 1 9140 Left Front Screen Side Extension
25-8528 1 9140 Left Front Solid Side Extension
4 25-8519 1 9124 Right Front Screen Side Extension
25-8523 1 9124 Right Front Solid Side Extension
25-8527 1 9126 Right Front Screen Side Extension
25-8525 1 9126 Right Front Solid Side Extension
25-8547 1 9128 Right Front Screen Side Extension
25-8545 1 9128 Right Front Solid Side Extension
25-8543 1 9130 Right Front Screen Side Extension
25-8541 1 9130 Right Front Solid Side Extension
25-8535 1 9136 Right Front Screen Side Extension
25-8533 1 9136 Right Front Solid Side Extension
25-8531 1 9140 Right Front Screen Side Extension
25-8529 1 9140 Right Front Solid Side Extension
5 25-8506 1 Fold Down, Solid Front Extension
25-8505 1 Bolt On, Solid Front Extension
6 100-8016 4 Hinge Mount Tab
7 25-8081 1 Linkage Pipe Assembly
8 25-8082 1 Handle Welded Assembly
9 25-8507 1 Handle Pivot Bracket
10 16-0027 2 Swivel Eyelet
11 813-5020-Z 2 1/2”-20 Fine Threaded Nut Zinc
12 100-8020-64 2 Gate Stop Sleeve
13 51-0003 1 Rubber Grip
14 25-8516-6 2 Extension Upright Cover
