1-800-325-9103
9100RT - 79 - www.meyermfg.com
KEY PART NUMBER QTY DESCRIPTION
1 25-8190-1 1 Grain Kit Main Body
2 625-0023-2 1 Door Weldment
3 124 3 1” Pillow Block Bearing
4 323 2 1” Lock Collar
5 10-0001 3 50B13 Sprocket, 1” Bore, 1/4” Keyway, W / Set Screws
6 23-0099 1 Lower Gate Shaft 1” x 32”
7 851-3816-2Z 2 3/8”-16 x 2” Bolt
8 15-0006-1 1 Universal Knuckle
9 15-0006-2 2 Universal Sleeve Assembly
10 815-3816-Z 2 3/8”-16 Nylon Locknut
11 15-0006 1 Complete Universal Knuckle / Sleeve Assembly
12 25-8062 1 Grain Kit Door Handle
13 49-0097 1 Plexiglas Window 6-1/2” x 23-1/2”
14 33-0049 5.16’ Window Weather-Strip (By The Foot)
15 49-0124 2 Poly Bottom Panel
16 49-0132 1 Chain Return Belt Seal
17 33-0028 2 Handle Nut
18 811-5013-4Z 2 1/2” x 4” Eyebolt (6” Overall)
19 49-0126 1 Rear Trough Belting
20 49-0125 1 Front Trough Belting
21 805-0038-Z 2 3/8” Flat Washer
22 14-0036 1 3/8” Lock Collar
23 25-8190-4 1 Door Latch Weldment
24 100-8180-5-2 2 Stabilizing Leg
32-0040 2 Lynch Pin
25 56-0115 2/4 Red Stop / Tail / Turn Lights
56-0081 2/0 Amber Turn Signal Light (Mounted On Ag Cart Only)
26 56-0082 4 Oval Grommet
27 56-0070-LED 3 2” Clearance Light With Grommet
56-0070-2 3 2” Round Grommet
28 56-0102 1 LED Light Harness
29 56-0103 1 Y-Harness Splitter
30 25-8190-7 2 Shield Panel
31 23-0113 1 Upper Shaft To Handle 1” x 30”
32 25-8190-2 1 Center Divider
33 49-0137 1 Side Shield Belting Left, Rear
34 49-0138 1 Side Shield Belting Right, Rear
35 49-0139 1 Side Shield Belting Left, Front
36 49-0140 1 Side Shield Belting Right, Front
37 56-0103-1 1 6-Pin Plug W / Lanyard & Crimp
38 29-0015 1 Spring
39 49-0152 2 Side Gate Belting Seal 2” x 64”
40 25-8190-9 2 Belting Strip
41 25-8190-10 2 Belting Strip
42 25-8190-11 2 Belting Strip
43 49-0161 2 Side Panel Belting
To Next Page
