KEY PART NUMBER QTY DESCRIPTION
1 10-0001 3 50B13 Sprocket, 1” Bore, 1/4” Keyway, W / Set Screws
2 100-8180-1 1 Double Door Grain Kit Main Body Weldment
3 25-8190-2 1 Center Divider
4 100-8180-5-2 2 Stabilizing Leg
32-0040 2 Lynch Pin
5 124 3 1” Pillow Block Bearing
6 14-0036 1 3/8” Lock Collar
7 15-0006 1 Complete Universal Knuckle / Sleeve Assembly
8 15-0006-1 1 Universal Knuckle
9 15-0006-2 2 Universal Sleeve Assembly
10 851-3816-2Z 2 3/8”-16 x 2” Bolt
11 815-3816-Z 2 3/8”-16 Nylon Locknut
12 23-0099 1 Lower Gate Shaft 1” x 32”
13 23-0113 1 Upper Shaft To Handle 1” x 30”
14 25-8062 1 Grain Kit Door Handle
15 25-8190-4 1 Door Latch Weldment
16 323 2 1” Lock Collar
17 33-0049 5.16’ Window Weather-Strip (By the Foot)
18 33-0049 2.15’ Window Weather-Strip (By the Foot)
19 49-0097 1 Plexiglas Window 6-1/2” x 23-1/2”
20 49-0124 2 Poly Bottom Panel
21 49-0125 1 Front Trough Belting
22 49-0129 1 Plexiglas Window 4-1/4” x 10”
23 49-0126 1 Rear Trough Belting
24 625-0023-2 1 Door Weldment
25 805-0038-Z 2 Flat Washer 3/8”
26 100-8180-3 1 Left Double Door Grain Kit Mount Weldment
27 100-8180-4 1 Right Double Door Grain Kit Mount Weldment
28 49-0132 1 Chain Return Belt Seal
29 56-0115 2/4 Red Stop / Tail / Turn Lights
56-0081 2/0 Amber Turn Signal Light (Mounted On Ag Cart Only)
30 56-0082 4 Oval Grommet
31 56-0070-LED 3 2” Clearance Light With Gromet
56-0070-2 3 2” Round Grommet
32 56-0102 1 LED Light Harness
33 56-0103 1 Y-Harness Splitter
34 56-0103-1 1 6-Pin Plug w/Lanyard & Crimp
35 49-0139 1 Side Shield Belting Left, Front
36 49-0140 1 Side Shield Belting Right, Front
37 49-0137 1 Side Shield Belting Left, Rear
38 49-0138 1 Side Shield Belting Right, Rear
39 133-BSE-.38-.25-1 AR Bulb Seal Edge Grip (By the Foot)
40 25-8190-7 2 Shield Panel
