Record-Mode
In this mode, triggers are set for the desired
steps. These can be edited by their
corresponding parameters.
Newly set steps are automatically in Edit-Mode
(they flash red).
Already existing steps can be edited by holding
down the INSTRUMENT/SEL(Select) key in
conjunction with the step to be edited.
Selection of Instruments
To enter Record-Mode hold the MAN TRG/RECORD
key, and press a corresponding instrument key.
The LED above the MAN TRG/RECORD key lights up
red. The display shows the selected instrument
as well as two additional parameters that can
be set by the DATA1 and DATA2 encoders.
U310+1!R4/1Z!()1!-21>*4.+3A!Q1,/*4,1E!4-120/*,B!Q4E1+!Manual-Mode*0,E*Step -
