Pattern selection
• Press the Pattern key in conjunction with one
of the upper black keys.
• Display shows LOAD PATTERN.
• The black keys are marked from 0-9.
• To select Pattern 01, first press 0 and then
1.
• This selection pattern applies up to the 99th
pattern location.
• Alternatively, patterns can be selected using
the DATA1 encoder.
The first 16 patterns are preset by MFB.
Try these out to test the device functions.
Pattern Chains
16 chains of patterns can be programmed
consecutively.
These can be selected as follows:
• Press Chain and one of the top black keys.
• Display shows No. and Pattern.
• No. is the number of patterns in the
already programmed chain.
• Pattern: Number of patterns which should be
played.
• Confirm with INSTRUMENT/SEL(Select).
Entering numerical values is identical to the
general pattern selection.
U310+1!,4/1Z!8/!*+!,4/!-4++*=31!/4!+1315/!0,!1Q-/A!-0//12,!7!
D4G!/4!+0>1!-0//12,+!50,!=1!94.,E!.,E12!Shift*Functions.*
