2
2-23
S a f e t y S y s t e m s
D. AIRBAG
As shown in the Figure D, the side
curtain airbag is installed at the side
wall and roof joint, on the roof lining.
SUPPLEMENTARY RESTRAINT SYSTEM (SRS)
1. Hitting the shoulder, edge of
pavement or hard surface
2. Fall into or drive into a deep pit/
Wheel hard landing or vehicle fall
Airbag Deplyoment Conditions
