Cermet II User’s Manual
30 97049 Issue 25.3, October 2016
APPENDIX B
Appendix B Setup Codes
CAL Calibration modes for input and output
DEFAULT VALUE = 052
Digit 1st digit (left most)
Calibration Mode
2nd digit
Calibration Function
3rd digit
Object for Calibration
0
Calibration functions as
per 2nd and 3rd digit
No function No function
1
Set baud rate, parity and
serial address
Manual calibration (channel as per 3rd
digit)
Processed result (dew
point, ppm
V
, lbs/MMSCF,
g/m
3
)
2 N/A N/A Pressure input
3 N/A N/A N/A
4 N/A N/A N/A
5 N/A Manual adjust N/A
6 N/A
Analog output scaling (analog channel
as per 3rd digit)
N/A
CODE 1 Tendency Indication, Additional LED’s, Display data source, Flashing,
Decimal points, Rounding
DEFAULT VALUE = 200
Digit 1st digit (left most)
Additional LED’s
2nd digit
Display Data Source
3rd digit
0 only (No Function)
0
LED annunciators are
always off
Processed data - result (dew point,
ppm
V
, lbs/MMSCF, g/m
3
)
N/A
1
LED annunciators are
on when relays are de-
energized
Processed data - channel 1 (dew
point only)
N/A
2
LED annunciators are on
when relays are energized
Processed data - pressure N/A
CODE 3 Serial mode and analog output source
DEFAULT VALUE = 000
Digit 1st digit (left most)
Serial Mode
2nd digit
Analog Output 1 Source
3rd digit
0 only (No Function)
0 ASCII mode
Analog output 1 from processed
result data (dew point, ppm
V
, lbs/
MMSCF, g/m
3
)
N/A
1 N/A
Analog output 1 from processed data
(dew point only)
N/A
2 N/A
Analog output 1 from processed data
(pressure)
N/A
