APPENDIX C
Appendix C Register Settings Accessible by Digital Communication
Register
Number
Function Read Only
1 Alarm Status
2 N/A
3 Processed Data – Result

4 Processed Data – Channel 1 (dew-point)

5 Processed Data – Channel 2 (pressure)

6 Setpoint 1
7 Setpoint 2
8 Setpoint 3
9 Setpoint 4
10 to 23 N/A
24 Scale Value – Result
25 Scale Value – Channel 1
26 Scale Value – Channel 2
27 Offset Value – Result
28 Offset Value – Channel 1
29 Offset Value – Channel 2
30 to 33 N/A
34 D/A Zero – Analogue O/P 1
35 N/A
36 D/A Full Scale – Analogue O/P 1
37 to 64 N/A
65 Hysteresis - Setpoint 1
66 Hysteresis - Setpoint 2
67 Hysteresis - Setpoint 3
68 Hysteresis - Setpoint 4
69 to 70 N/A
71 Make Delay - Setpoint 1
72 Make Delay - Setpoint 2
73 Make Delay - Setpoint 3
74 Make Delay - Setpoint 4
75 to 76 N/A
77 Break Delay - Setpoint 1
78 Break Delay - Setpoint 2
79 Break Delay - Setpoint 3
80 Break Delay - Setpoint 4
81 to 128 N/A
129 Cal Mode
130 Code 1
131 Code 2
132 Code 3
