MICRO-EPSILON induSENSOR EDS Series User Manual

Page 25
induSENSOR, EDS
Dimensional drawing, model EDS- ... -Z
Alu tube I
Sensor rod L
33 (1.3)
21(0.82)
12
(0.47)
1 x 45 °
M24x1.5
ø44
-0.1
(1.73
-0.004
dia.)
ø44
-
0.3
(1.73
-
0.12
dia.)
ø48f7 (1.89 dia.)
d
D
Fig. 16 induSENSOR with axial wires,
model EDS- ... -Z, dimensions in mm (inches),
not to scale
Measuring
range
Sensor rod Alu tube
L D I d
220 (8.66) 252 (9.92) 10 (.39) 250 (9.84 16 (.63)
260 (10.23) 292 (11.50) 10 (.39) 290 (11.42) 16 (.63)
300 (11.81) 341 (13.43) 10 (.39) 340 (13.39) 16 (.63)
370 (14.57) 457 (17.99) 12 (.47) 450 (17.72) 18 (.71)
400 (15.74) 457 (17.99) 12 (.47) 450 (17.72) 18 (.71)
Dimension
Fit tolerance
µm
48f7
-25
-50
