2.3 General Specifications
Sensor Controller
Protection class IP 65
Operating temperature See also Chapter Measurement
Specification, see Chap. 2.5
0 ... 85 °C (+32 ... +185 °F)
Storage temperature See also Chapter Measurement
Specification, see Chap. 2.5
-40 ... 85 °C (-40 ... +185 °F)
Relative humidity 10 ... 95 %, non-condensing
Material Stainless steel Die casting zinc
Dimensions 28 mm x 14 mm, M12x1 89 mm x 70 mm x 30 mm
Dimensions CTH, CTP 55 mm x 29.5 mm, M18x1
(with massive housing)
89 mm x 70 mm x 30 mm
Weight 40 g 420 g
Cable length 1 m (only CT-SF02, CT-SF15, CT-SF22, CT-SF15, CT-SF22),
3 m (standard at CTH, CTM
1 a
nd CTP),
8 m, 15 m
Cable diameter 2.8 mm
Ambient temperature
cable
Max. 180 °C
[High temperature cable for CtH: 250 °C]
Vibration IEC 68-2-6: 3 g 11 - 200 Hz, any axis
Shock IEC 68-2-27: 50 g, 11 ms, any axis
CompactConnect
Software
optional
Electromagnetic
compatibility (EMC)
EN 61326-1: 2006 and EN 61326-2-3: 2006
1) The CTM-3 models are only available with 3 m cable.
