2.5.3 CTM / CTP Models
Model CTM-1SF40 CTM-1SF75 CTM-1SF75H1 CTM-2SF40
Temperature range
(scalable)
485 ... 1050 °C 650 ... 1800 °C 800 ... 2200 °C 250 ... 800 °C
Operating temperature
(sensor)
-20 ... 100 °C -20 ... 100 °C -20 ... 100 °C -20 ... 125 °C
Operating temperature
(sensor)
-40 ... 100 °C -40 ... 100 °C -40 ... 100 °C -40 ... 125 °C
Spectral range 1 μm 1,6 μm
Optical resolution 40:1 75:1 75:1 40:1
System accuracy
1 2
± (0.3 % of reading + 2 °C)
3
Repeatability
1
± (0.1 % of reading + 1 °C)
3
Temperature coefficient
5
±0.05 K/K or ±0.05 %/K (whichever is greater)
Temperature resolution 0.1 °C
3
Exposure time (90 % signal) 1 ms
4
Emissivity / gain 0.100 ... 1.100 (adjustable via programming keys or software)
Transmissivity 0.100 ... 1.100 (adjustable via programming keys or software)
Signal processing Average, peak hold, valley hold (adjustable via programming keys or software)
Software (optional) CompactConnect
1) At operating temperature 23 ±5 °C.
2) Accuracy for thermocouple output: ±2,5 °C or ±1 %
3) e = 1 / Response time 1 s
4) With dynamic adaptation at low signal levels
5) For ambient temperatures (sensor): 18 °C ≤ sensor ≤ 28 °C
