Technical Data
thermoMETER CT
2.5 Measurement Specifications
2.5.1 CT Model
Model CT-SF02 CT-SF15 CT-SF22
Temperature range (scalable) -50 ... 600 °C -50 ... 600 °C -50 ... 975 °C
Operating temperature (sensor) -20 ... 130 °C -20 ...180 °C -20 ...180 °C
Storage temperature (sensor) -40 ... 130 °C -20 ... 180 °C -20 ... 180 °C
Spectral range 8 ... 14 μm
Optical resolution 2:1 15:1 22:1
System accuracy
1 2
±1 °C or ±1 %
3
Repeatability
1
±0.5 °C or ±0.5 %
3
Temperature coefficient
5
±0.05 K/ K or ±0.05 %/ K (whichever is greater)
Temperature resolution (NETD)
3 4
0.1 K 0.05 K
Response time (95 % signal) 150 ms
Warm-up time 10 min
Emissivity/ gain 0.100 ... 1.100 (adjustable via programming keys or software)
Transmissivity 0.100 ... 1.100 (adjustable via programming keys or software)
Signal processing Average, peak hold, valley hold
(adjustable via programming keys or software)
Software (optional) CompactConnect
1) At operating temperature 23 ±5 °C; whichever is greater.
2) Accuracy for thermocouple output: ±2.5 °C or ±1 %
3) At object temperatures > 0 °C; e = 1
4) At time constant 200 ms and an object temperature of 25 °C
5) For ambient temperatures (sensor): 18 °C ≤ sensor ≤ 28 °C
i
On the CT models CT-SF02 the sensor cable must not be moved during the measurement.
